Featured Products
Xicoy X90 & X120 Turbojet Engines
Xicoy LGC15 Electronic Controller/Sequencer for E-Landing Gear
Sequencer - Pressure monitor - Pressure failsafe - Pressure telemetry.
The latest buzz in the Jet Scene, Xicoy's latest creation Digital weight and balance meter. Order your today. Delivery mid to late March 2015.
After 10years of service the M160 has been shelved for a brand new engine, and the new standard in 200N Turbines, Introducing the:
M200XBL
FEATURES
Single fuel input directly from the pump, and a 3-wire electrical connection to the ECU that carry the battery power and a bidirectional digital bus.
All engine parameters and timers are stored in the engine, installation parameters (radio settings,etc) are stored in the ecu, enabling the swap of the engine without any adjust.
Full Brushless Technology.
SPECIFICATIONS
Nominal thrust: 200N (45lb) @ 120,000 RPM
Idle thrust: 7N @ 32,000 RPM
Diameter: 110mm (4.3”)
Engine weight: 1.5Kg (3.3lb)
Installed weight: 1.65Kg (3.65lb)
Fuel: Kerosene + 3% - 5% oil
EGT typical: 650ºC
Fuel comsumption: 550gram/min
Start mode: Direct Kerosene, internal ignitor
The M200XBL will not only lead its class in performance, it will set a new standard for price per N of thrust.
First Look at our
Xicoy Trailing Link Struts
(Available Now)
JETS MUNT NEWS
JETS MUNT GOES BRUSHLESS
JetsMunt has been busy working on developing better technology to further increase reliabilty of our turbines.
The standard has been to use common brushed DC motors for both Fuel Pump and Starter Motors. Having served us all well for years, these two items have been the sourse of most of, if any problems, and so, Jets Munt has taken the next evolutionary step in the design and manufacture of the worlds first Digitally Controlled Brushless Fuel Pump and Starter Motors.
Most Jets Munt Engines will receive the Upgrade with the first to be the M100XBL ready for delivery from 10th June 2013.
JPA is proud to offer Jet Teng Models to our lineup of speciallized products.
NEW xXxjet
Length:1700mm(67in)
Wing Span:1490mm(58.5in)
Material:All Composit
Fan:110-127mm
Power: 6kg-8kg
Designed as an EDF jet we are going to convert the model for turbine use. Matched with either of our VT80 or M100X turbines, it will surely be an exciting combination.
Check out the build section for photos of the first Australian xXxjet VT80 Turbine Conversion.
Jets Munt Latest Offering, The Merlin 100X
Nominal thrust: 100N (22,5lb) at 152.000 RPM
The succesful M100 engine has been elected to be the first to receive our new electronic system.
Sensors and valves are installed inside the motor, simplifying installation.
The engine has only one fuel input directly from the pump, and a 3-wire electrical connection to the ecu that carry the battery power and a bidirectional digital bus. All measures and data from the engine are transmitted to the ecu in digital data format, using a high speed propietary protocol specially developped for this application. The bus design allow a distance up to 15meters from engine to ecu while keeping the generated noise by the bus to a very low level to not affect other devices nor to be affected by them.
All engine parameters and timers are stored in the engine, installation parameters (radio settings,etc) are stored in the ecu, enabling the swap of the engine without any adjust.
http://www.youtube.com/watch?v=cm7c2n3WMrA
Jet Products Australia represent, in Australia and New Zealand, only products that we have extensively tested and models that we have actually flown. Jet Products Australia is more about quality rather than quantity and believe that when making an investment in an expensive jet there is no point in buying cheap and unreliable parts to drive it. A few dollars saved in the short run can lead to thousands being waisted in the long run.
Products that we are proud to represent:
* Jets Munt Turbines
* Tomahawk Jets
* Fox-Composite Hawk
* KingTech Turbines
* Jersey Modeler Fuel Systems
* Professional Build Service
* Turbine Repair and Service
At Jet Products Australia we also work very closely with other established specialists, such as Intairco in Melbourne, to ensure the overall customer experience is not only met but surpassed.
Jet Products Australia are in the business of helping you achieve your jet dreams.
NOTE ON ALL PRICING - Due to wild fluctuations on foreign exchange, prices will be confirmed at purchase.
EDF Viper Jet on a low pass!
FREE LISTING FOR ALL SECOND HAND JET PRODUCTS
Jet Products Australia is happy to present and list jets for sale as a service to the jet community worldwide.
